Air compressors may not be the flashiest equipment in the lab, yet they play a critical role truly behind the scenes. They provide a clean, dry stream of compressed air-a surprising number of essential tasks run on them.
| Specification | LNG10 | LNG20 | LNG40 | LNG80 |
|---|---|---|---|---|
| Liquid Nitrogen Volume (L/day) | 6 to 10 | 15 to 20 | 40 to 45 (Boost Function) | 60 to 80 (Boost Function) |
| Built-in Dewar Capacity (L) | 35 | 50 (Optional 35) | 100 | 210 |
| Air Compressor | Included | Included | Included | Included |
| Control System | Colour Graphic Touch Screen | Colour Graphic Touch Screen | Colour Graphic Touch Screen | Colour Graphic Touch Screen |
| Power Supply | 110V 50/60Hz 230V 50/60Hz | 230V 50/60Hz | 380/400/415V – 50Hz 3P 460/480V – 60Hz 3P 200V – 50/60Hz | 380/400/415V – 50Hz 3P 460/480V – 60Hz 3P |
| Power Consumption (kW) | 1.9 | 3.2 | 4.0 | 6.9 |
| Max Altitude (m) | Up to 2,000 | Up to 2,000 | Up to 2,000 | Up to 2,000 |
| Ambient Temperature Range (°C) | +5 to +28 | +5 to +28 | +5 to +35° +5 to +28 | +5 to +35° |
| Noise Level (dBA) | <55 | <60 | <60 | <65 |
| Dimensions (L × W × H cm) | 68 × 89 × 171 | 148 × 66 × 186 | 148 × 66 × 186 | 172 × 82 × 187 |
| Weight (kg) | 270 | 446 | 463 491* | 615 |
| Water Cooled Version | Not Available | Not Available | Available (LLN40) | Standard |
| Ordering Information | LLN10+ | LLN20AC (LLN20ACCOMP) | LLN40AC | LLN80 |
