Organic Elemental Analysis ECS 8022 is the specialized N and C Elemental Analyzer Model based on the Dumas combustion method.
ECS 8022 is prepared and dedicated to the carbon and nitrogen determination in a wide range of samples. ECS 8022 is based on sample combustion and separation of gases with a chromatographic column.
The combustion products, i.e. CO2 and N2 are separated and quantified by a high resolution TCD detector.
ECS 8022 is fully automatic, from the available samplers to the oxygen dosage, from the monitoring of consumables status to the automatic leak test.
|
Type
|
CN
|
|
|
|
Upgradable to CHNS-O
|
|
|
Analysis Time
|
CN
|
5 min
|
|
Analytical Rang
|
C
|
0.002 - 20 mg
|
|
N
|
0.002 - 20 mg
|
|
|
Accuracy*
|
<0.2% (certified standard; purity >99.9%)
|
|
|
Precision*
|
<0.1% (certified standard; purity >99.9%)
|
|
|
Sampler
|
Pneumatic auto sampler
|
147 positions max
|
|
Electronic auto sampler
|
32, 50, 100 positions
|
|
|
Manual sampler
|
||
|
Dual furnace system
|
||
|
Safety quick fit system
|
||
|
Touch screen display
|
||
|
Standby mode
|
||
